Laboratory Glassware >

Reduction Adapters

Reduction Adapters

Categories:

Model No: AGN-1323
It is a laboratory or industrial glassware component used to connect two pieces of equipment or tubing with different joint sizes. It allows seamless transition between larger and smaller standard taper joints, enabling flexibility in combining various apparatus components. Reduction adapters are commonly made from borosilicate glass, plastic, or metal, depending on the application. They are widely used in distillation setups, condensers, flasks, and vacuum systems.

Shere

Technical Specifications

  • Size Compatibility: Connects two glassware pieces with different standard taper joint sizes (e.g., B 29 to B 24).
  • Laboratory Standard Tapers: Available in common joint sizes (e.g., B 10 to B 19, B 24 to B 14).
  • Chemical Resistance: Typically made of borosilicate glass, resistant to thermal shock and most chemicals.
  • Precision Ground Joints: Ensures airtight and secure fit between connected parts.
  • Types of Reductions:
    • Male-to-Female: Larger female joint at the bottom, smaller male at the top.
    • Female-to-Male: Smaller female at the bottom, larger male at the top.
  • Heat-Resistant: Can be used in heated systems or under vacuum when made from appropriate material.
  • Versatile Use: Commonly used in distillation, reflux, and other chemical processing setups.
  • Optional Stopcock or Side Arm: Some models include a stopcock for controlled addition or venting.

Cat. No. Socket (Female Joint) Cone (Male Joint)
1323/1 B 14 B 19
1323/2 B 14 B 24
1323/3 B 14 B 29
1323/4 B 19 B 24
1323/5 B 19 B 29
1323/6 B 19 B 34
1323/7 B 19 B 40
1323/8 B 19 B 45
1323/9 B 19 B 55
1323/10 B 24 B 29
1323/11 B 24 B 34
1323/12 B 24 B 40
1323/13 B 24 B 45
1323/14 B 24 B 50
1323/15 B 24 B 55
1323/16 B 29 B 34
1323/17 B 29 B 40
1323/18 B 34 B 40
1323/19 B 34 B 50
1323/20 B 34 B 55
1323/21 B 40 B 55
