PENTA HEAD MICROSCOPE

PENTA HEAD MICROSCOPE

<
PENTA – HEAD MICROSCOPE PENTA – HEAD MICROSCOPE
>
DECA HEAD MICROSCOPE DECA HEAD MICROSCOPE

Categories: ,

Model No: AGN-PHM -777
Magnification 1000x
Model Number AGN-PHM -777
Brand AGN
Is It Portable Non-Portable
Power 110v-240v
Objectives Achromatic Objectives
Mechanical Stage 140mm X 140mm
Condenser Movable Abbe Condenser
Enquire Now

Shere

Technical Specifications

Optical System:
  • Finite optical system providing high-quality imaging.
  • Magnification range: 40× – 1000×.
Stand:
  • Durable aluminium die-cast stand with anti-rust finish for long-lasting stability.
Viewing Head:
  • Trinocular or binocular main head inclined at 45° for ergonomic viewing.
  • Interpupillary distance (IPD): 48–75 mm.
  • Additional binocular head for co-observers.
Eye Guards:
  • Adjustable rubber eye guards for comfortable observation.
Eyepieces:
  • Wide-field 10× eyepieces with 18 mm F.O.V.
  • ±5 diopter adjustment.
  • Anti-fungal and anti-reflection coated.
Nosepiece:
  • Quadruple revolving nosepiece with click-stop mechanism and rubber grip for smooth rotation.
Objectives:
  • Achromatic objectives:
    • 4× N.A. 0.10
    • 10× N.A. 0.25
    • 40× N.A. 0.65 (spring-loaded)
    • 100× N.A. 1.25 (spring-loaded, oil immersion)
Middle Module:
  • LED pointer cursor with adjustable green intensity.
Mechanical Stage:
  • Ceramic-coated double-plate graduated stage, 140 × 140 mm.
  • X/Y travel range: 75 × 55 mm.
  • Scratch-resistant surface with double specimen holder clips.
Focusing:
  • Coaxial coarse and fine focusing knobs.
  • Vertical coarse travel: 25 mm; fine precision: 1 μm.
Condenser:
  • Movable Abbe condenser, N.A. 1.25.
  • Anti-fungal and anti-reflection coating with aspheric lens.
  • Iris diaphragm with frosted white/blue filters.
Illumination:
  • 5W LED light with intensity controller.
  • Lifespan up to 100,000 hours.
Power Supply:
  • Universal input 110–240V AC integrated with voltage fluctuation stabilizer.
Packaging:
  • Inner protective thermocol/styrofoam packaging.
  • Outer cardboard box for safe transport.
