Horizontal Single Stage Quartz Distillation Horizontal Quartz Boiler fitted

Horizontal Single Stage Quartz Distillation Horizontal Quartz Boiler fitted

Model No: AGN.3563

Shere

Technical Specifications

  • Equipped with a removable silica-sheathed (quartz) heater and coil condenser, complete with stand, clamps, and accessories.
  • Conductivity of Distilled Water: 1–1.5 µS/cm with Borosilicate condenser, 0.5–0.8 µS/cm with Quartz condenser.
  • pH: 6–7.
  • Screw-threaded connectors allow easy cleaning when scaling occurs.
  • All components are replaceable.
  • Includes automatic safety cut-off.

Cat. No. Boiler Type Condenser Type Output (approx. Ltr./Hr.) Power Rating (kW)
AGN.3563.01 Quartz Borosilicate 2 1.7
AGN.3563.02 Quartz Quartz 2 1.7
AGN.3563.03 Quartz Borosilicate 5 3.5
AGN.3563.04 Quartz Quartz 5 3.5
