SEED GERMINATOR

SEED GERMINATOR

Categories:

Model No: AGN-147
Double wall seed germinator is a precision laboratory equipment designed to create a controlled environment for seed germination and plant growth experiments. It features a double-walled chamber with an inner stainless steel (SS) lining and a powder-coated mild steel outer shell, ensuring durability, efficient insulation, and optimal internal conditions. It maintains precise temperature and humidity using advanced control systems, making it suitable for agricultural research, seed testing, and biological studies.
Enquire Now

Share

Technical Specifications

  1. Double Wall Construction:
    • Inner chamber made of stainless steel (SS) for resistance to corrosion and easy cleaning.
    • Outer chamber made of mild steel sheet with durable powder coating.
  2. High-Quality Insulation:
    • Glass wool or PUF insulation between the walls minimizes thermal loss, improving energy efficiency and maintaining stable internal conditions.
  3. Trays for Sample Placement:
    • Equipped with 14 aluminum perforated trays that allow uniform airflow and convenient sample organization.
  4. Uniform Temperature and Humidity:
    • Air circulation system ensures even distribution of heat and moisture throughout the chamber.
  5. Clear Viewing Door:
    • Full-length transparent acrylic door provides an internal view without the need to open the chamber, maintaining internal stability.
  6. Power and Lighting Controls:
    • Mains voltage indicator for monitoring power supply.
    • Internal fluorescent lighting simulates daylight for plant growth.
    • Day-night cyclic timer automates lighting periods to replicate natural light cycles.
  7. Precise Temperature Control:
    • Temperature range: 5°C to 60°C.
    • Controlled by:
      • Precision thermostat (±1°C accuracy), or
      • Microprocessor-based digital temperature-humidity controller (±0.5°C accuracy).
  8. Advanced Humidity Control:
    • Independent steam generator provides humidity control from ambient to 95% RH, accurate to ±0.5%.
    • Includes a low water safety cutoff device to prevent equipment damage and ensure user safety.
  9. Power Requirements:
    • Operates on 220/230 Volt AC, 50 Hz—compatible with standard laboratory electrical systems.
Model No.    Inner Size ( W x D x H )mm Capacity Liters
      AGN-147 A 555 x 605 x 910 ( Single Chamber ) 310
      AGN-147 B 555 x 605 x 910 ( Dual Chamber With Each chamber ) 620
  Optional:
  1. Combined Humidity and Temp Controller PLC With 21 CFR output and Real Time data backup with Software.
  2. Suitable Voltage Stabilizer.
