plant growth chamber

PLANT GROWTH CHAMBER

Categories: ,

Model No: AGN-148
Plant Growth Chamber is a specialized laboratory device designed to simulate natural environmental conditions to support and study plant growth under controlled settings. It provides regulated temperature, humidity, and light conditions, making it ideal for plant physiology research, tissue culture, seedling growth, and botanical experiments.
Enquire Now

Shere

Technical Specifications

  1. Robust Double Wall Construction:
    • Inner chamber and shelves made from 5.5-grade stainless steel sheet for corrosion resistance and durability.
    • Outer body made of mild steel sheet, powder coated for long-lasting protection.
    • Mounted on castor wheels for easy movement and positioning.
  2. High-Performance Insulation:
    • Gap between the inner and outer walls is filled with high-grade glass wool or PUF insulation, effectively minimizing thermal loss and improving energy efficiency.
  3. Efficient Air Circulation:
    • Equipped with an air circulation fan to ensure uniform temperature and humidity throughout the chamber.
  4. Transparent Inner Door:
    • Acrylic inner door allows for clear viewing of the plant samples without disturbing the internal environment.
  5. Internal Illumination:
    • Fitted with fluorescent tube lighting, suitable for simulating daylight conditions needed for photosynthesis and plant growth.
  6. Refrigeration System:
    • Integrated refrigeration unit enables precise cooling, making the chamber suitable for both cold and warm growth conditions.
  7. Temperature Control:
    • Temperature Range: +5°C to 60°C.
    • Controlled by Microprocessor-based PID Digital Temperature Controller.
    • Accuracy: ±0.5°C (display) with system control within ±1°C.
  8. Humidity Control:
    • Fitted with an independent steam generator to provide controlled humidity.
    • Humidity Range: Ambient to 95% RH.
    • Control Accuracy: ±2% RH.
    • Includes low water level safety cutoff to prevent overheating and equipment damage.
  9. Power Supply:
    • Operates on 220/230 Volt AC, 50Hz, suitable for standard laboratory power sources.

Model No. Inner Size (W x D x H) Capacity Cubic Feet Capacity Liters
      AGN-148A 570 x 875 x 550 mm 10 280
      AGN-148B 775 x 900 x 775 mm 20 560
      AGN-148C 835 x 1200 x 825 mm 30 840
      AGN-148D 900 x 1720 x 800 mm 45.8 1282
  Optional:
  1. Combined Humidity and Temp Controller PLC With 21 CFR output and Real Time data backup with Software.
  2. Automatic Voltage stabilizer
