STABILITY CHAMBER PHARMACEUTICALS GRADE

STABILITY CHAMBER PHARMACEUTICALS GRADE

Categories: ,

Model No: AGN-150
Stability Chamber is a precision-engineered testing unit designed to create stable temperature and humidity conditions over extended periods. It is used primarily in the pharmaceutical, biotechnology, and research industries to test product stability, shelf-life, and reliability under controlled environmental conditions. The NU-150 model features an advanced Micro PLC-based controller for enhanced automation and monitoring.
Enquire Now

Shere

Technical Specifications

  • Temperature High Cut-Off (°C.THC1): Automatically cuts off the heating and humidity systems when the set high-temperature limit is exceeded, with audio-visual alarm indication.
  • Temperature Low Cut-Off (°C.TLC1): Cuts off the refrigeration system if the temperature falls below the defined lower limit, accompanied by audio-visual indication.
  • Humidity High Cut-Off (%RHC1): Triggers an audio-visual warning when the humidity level exceeds the high set point.
  • Humidity Low Cut-Off (%RLC1): Provides audio-visual indication if the humidity drops below the low threshold.
  • Display & Monitoring:
    • 124 x 64 Graphic Display: Clear and user-friendly interface for real-time data visualization.
    • Integrated data recorder to log temperature and humidity trends over time.
    • Compatible with PC software for data download and analysis.
  • Communication & Printing Interface:
    • Equipped with RS-485 communication port, enabling connectivity to external systems for data logging, remote monitoring, or printer interface.
  1. Temperature Range: 20°C to 60°C
  2. Temperature Accuracy: ± 0.2°C
  3. Temperature Uniformity: 1°C
  4. Humidity Range: 40% RH to 95% RH
  5. Humidity Accuracy: ± 2% RH
  6. Humidity Uniformity: ± 3% RH
Model Capacity Liter Internal Size  ( W x D x H )mm External Size  ( W x D x H )mm Tray Qty. Tray Size  mm Approx. Wt.  Kg Equip. Connected  Load Watt
      AGN-150SC-A 200 600 x 400 x 850 760 x 1030 x 1450 2 430 x 460 150 3.0
      AGN-150SC-B 400 700 x 600 x 950 860 x 1230 x 1550 3 530 x 560 250 3.0
      AGN-150SC-C 600 700 x 800 x 1100 860 x 1430 x 1700 3 630 x 660 275 4.0
      AGN-150SC-D 800 700 x 800 x 1450 860 x 1430 x 2100 4 730 x 760 350 5.0
      AGN-150SC-E 1000 800 x 800 x 1600 960 x 1430 x 2210 4 710 x 560 350 6.0
