Potentiometer 4-Wire with Pencil Jockey

Potentiometer 4-Wire with Pencil Jockey

Categories: ,

Model No: AGN-1026
Comprising four constantan wires of 24 SWG, one meter long, clamped under heavy Brass strips of SWG 18 and fitted by screws in such a manner so that it is easily replaceable and has negligible ‘END ERRORS’. Each block is fitted with a heavy lock type brass terminal which is mounted on an 18mmthick ply wooden board with mica on top. The four wires are stretched along the both ends of two full meter scales. Overall dimension: 1.12m x 100mm x 50mm high including terminals. Supplied complete with Pencil Jockey along with lead for connections & detailed working manual.
Enquire Now

Shere

Technical Specifications

  1. Wire Configuration:
    • Comprises four constantan wires of 24 SWG, each 1 meter long.
    • Wires are clamped under heavy brass strips of 18 SWG and fixed with screws.
    • Designed for easy replacement and negligible end errors.
  2. Terminals & Mounting:
    • Each wire block is fitted with a heavy lock-type brass terminal.
    • Terminals are mounted on an 18 mm thick ply wooden board with mica insulation on top.
  3. Wire Stretch & Scale:
    • The four wires are stretched along both ends of two full meter scales for accurate measurements.
  4. Dimensions:
    • Overall size: 1.12 m × 100 mm × 50 mm (height including terminals).
  5. Accessories & Documentation:
    • Supplied complete with Pencil Jockey, connecting leads, and a detailed working manual.
