PENETROMETER APPARATUS

Categories: Laboratory Instruments, Oil and Petroleum Equipments

Model No: AGN-528

[As per IP 49, 50 & 167 specifications and also per IS 1448 (P: 60) & (P: 93)] This apparatus is used for penetration test on a wide variety of materials. It consists of a head Support mounted on a vertical rod which can be adjusted for height. A rack and pinion and pointer assembly provides fine adjustment of needle tip to Sample and in Corporates a Slipping clutch mechanism which make reading of penetration and subsequent resetting a sample and accurate operation. The dial graduate from 0-400 in one tenth millimeter Sub Division. The Instrument is supplied with two sample containers & 2 Wts.

Shere

Technical Specifications

ACCESSORIES:

AGN-528	Optional Accessories
a.	Spare penetration Needle (Pack of Two)
b.	Spare penetration solid cone
c.	Spare penetration Brass hollow cone
d.	Grease worker hand operated
e.	Grease worker hand operated Big Handle (Lever Type)
f.	Grease cutter as per IP 50
g.	Transfer Dish
h.	Spare Sample Container (Set of 2)
i.	Spare Brass wts 50gm & 100gm (Set of 2)

TYPES:

Code	Types
AGN-529	Penetrometer with containers and weights having peneteration Needle. (Bitumen)
AGN-530	Penetrometer Apparatus with containers and weights having peneteration CONE HOLLOW type (Grease)
AGN-531	Same as above – but with Geared arrangement for moving the arm with geared unit
AGN-532	Penetrometer with Brass Cone & Needle With DIGITAL TIMMER DEVICE (Adjustable)
AGN-533	Same as above — but with Geared arrangement for moving the arm with geared unit
