PATHOLOGICAL TRINOCULAR MICROSCOPE

Categories: MICROSCOPES, Pathological Laboratory Microscopes

Magnification	1000x
Model Number	AGN-PTM-08
Brand	AGN
Focusing	Separate Coarse & Fine Focusing with 0.2mm/rotation.
Mechanical Stage	140mm x 140mm
Is It Portable	Non-Portable

Optical System: Finite optical system.
Stand: Aluminium die-cast body with anti-rust finish.
Viewing Head: Trinocular head, inclined at 45°, 360° rotatable, with IPD range 48–75mm and diopter adjustment.
Eye Guards: Adjustable rubber eye guards for comfortable viewing.
Eyepieces: Wide field 10x, FOV 16/18mm, antifungal and anti-reflection coated.
Nosepiece: Forward quadruple revolving nosepiece with click-stop mechanism and rubber grip.
Magnification: 40x to 1000x.
Objectives: Achromatic objectives 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 oil immersion (SL).
Mechanical Stage: Single-plate graduated stage, 140mm × 140mm, X/Y travel range 70mm × 50mm, with single specimen holder clip.
Focusing: Separate coarse and fine focusing, 0.2mm per rotation.
Condenser: Movable Abbe condenser, N.A. 1.25, antifungal and anti-reflection coated, with aspheric lens, iris diaphragm, and swing-in/out filter holder with frosted white/blue filter.
Illumination: Halogen 6V-20W (up to 20,000 hours) or 3W LED (up to 100,000 hours) with intensity control.
Power Supply: Universal 110V–240V, integrated with voltage flux stabilizer.
Packaging: Inner thermocol/styrofoam packing with outer cardboard box.
