Magnification	1000x
Illumination	LED
Model Number	AGN-PBM-09
Brand	AGN
Focusing	Co-axial Coarse And Fine Focusing With 0.2mm/rotation.
Mechanical Stage	135mm x 150mm
Is It Portable	Portable
Objectives	Semi Plan Achromatic Objective 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 Oil (SL).
I Deal In	New Only

Optical System: Finite optical system.
Stand: Durable aluminium die-cast stand with anti-rust coating.
Viewing Head: Sliding binocular head, inclined at 45°, fully rotatable 360°, with interpupillary distance (IPD) adjustment from 48–75 mm and diopter control.
Eye Guards: Rubber eye guards, adjustable for comfortable viewing.
Eyepieces: Wide-field 10x eyepieces with 18 mm F.O.V (optional 10x/20 mm), featuring anti-fungal and anti-reflective coating.
Nosepiece: Forward-facing quadruple revolving nosepiece with click-stop mechanism and rubber grip for smooth operation.
Magnification Range: 40x to 1000x.
Objectives: Semi-plan achromatic objectives – 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 oil immersion (SL).
Mechanical Stage: Double-plate graduated stage (135 mm × 150 mm) with X/Y travel of 80 mm × 55 mm and dual specimen holder clips.
Focusing: Co-axial coarse and fine focusing, with 0.2 mm per rotation.
Condenser: Movable Abbe condenser, N.A. 1.25, anti-fungal and anti-reflective with aspheric lens, iris diaphragm with frosted white/blue option.
Illumination: Halogen 6 V–20 W (up to 20,000 hours) or 3 W LED (up to 100,000 hours) with adjustable intensity control.
Power Supply: Universal input 110–240 V with integrated voltage stabilizer.
Packaging: Inner thermocol/styrofoam and outer cardboard box for secure transit.
