Liebig Condensers

Liebig Condensers

Categories:

Model No: AGN-1261
Liebig condenser with interchangeable joints is a common piece of laboratory glassware used for condensing vapors into liquids, particularly during distillation or reflux processes. It is a straight, double-walled tube design where a coolant (usually water) flows through the outer jacket while vapor travels through the inner tube, allowing efficient condensation.

Shere

Technical Specifications

  • Structure:
    • Inner tube: Straight, narrow bore where vapor passes.
    • Outer jacket: Surrounds the inner tube, allowing coolant (typically water) to flow around the vapor path.
    • Inlet and outlet tubes: For water to enter and exit the outer jacket.
    • Interchangeable joints: Standardized glass ground joints at both ends for easy assembly/disassembly with other glassware (e.g., flasks, adapters).
  • Material: Typically made of borosilicate glass, which is heat and chemical resistant.
  • Length: Varies, usually between 150 mm to 600 mm, depending on required efficiency and application.

Cat. No. Cone Socket Effective Length (mm)
1261/1 B 14 B 14 150
1261/2 B 19 B 19 200
1261/3 B 24 B 24 200
1261/4 B 19 B 19 300
1261/5 B 24 B 24 300
1261/6 B 19 B 19 350
1261/7 B 24 B 24 350
1261/8 B 19 B 19 400
1261/9 B 24 B 24 400
1261/10 B 24 B 24 500
1261/11 B 24 B 24 600
1261/12 B 24 B 24 750
1261/13 B 34 B 34 500
1261/14 B 34 B 34 600
1261/15 B 34 B 34 750
1261/16 B 34 B 34 900
1261/17 B 19 – 300
1261/18 B 24 – 350
1261/19 B 34 – 250
