ADVANCE INVERTED TISSUE CULTURE MICROSCOPE

ADVANCE INVERTED TISSUE CULTURE MICROSCOPE

ADVANCE INVERTED TISSUE CULTURE MICROSCOPE

<
INVERTED TISSUE CULTURE MICROSCOPE INVERTED TISSUE CULTURE MICROSCOPE
>
FLUORESCENCE ATTACHMENT RESEARCH TRINOCULAR MICROSCOPE FLUORESCENCE ATTACHMENT RESEARCH TRINOCULAR MICROSCOPE

Categories: ,

Model No: AGN-ITC-105S
Magnification 400x
Model Number AGN-ITC-105S
Brand AGN
Illumination 5W LED Light
Optical System Infinity Optical System
Mechanical Stage Graduated Stage Size 160mm X 250mm
Viewing Head Trinocular Head 30 Degree Inclined 360 Degree Rotatable
Enquire Now

Shere

Technical Specifications

  • Optical System: Infinity-corrected optical system for high-resolution imaging.
  • Stand: Robust single-mould aluminum die-cast body with anti-rust finish.
  • Viewing Head: Trinocular head inclined at 30°, fully rotatable (360°), with interpupillary distance adjustment from 48–75 mm and diopter correction.
  • Eye Guards: Adjustable rubber eye guards for comfortable observation.
  • Eyepieces: Wide-field 10x eyepieces with 22 mm field of view, ±5 diopter adjustment, antifungal and anti-reflective coating.
  • Nosepiece: Quintuple revolving nosepiece with click-stop mechanism and rubber grip for smooth operation.
  • Objectives: LWD Plan objectives:
  • 4x/0.10
  • 10x/0.25 PH
  • 20x/0.50 PH
  • 40x/0.65 PH
  • Magnification Range: 40x to 400x.
  • Phase Annulus: Fixed and adjustable phase plates for 10x, 20x, and 40x objectives.
  • Mechanical Stage: Graduated stage (160 mm × 250 mm) with X/Y travel of 78 mm × 54 mm, scratch-resistant surface, and dual specimen holder clips.
  • Focusing: Coaxial coarse and fine focusing with 0.002 mm fine adjustment scale.
  • Condenser: LWD 45 mm condenser, N.A. 0.35, with field diaphragm and pull-out filter socket.
  • Filters: Blue, green, and yellow glass filters included.
  • Illumination: 5W LED light with adjustable intensity, offering up to 100,000 hours of operation.
  • Power Supply: Universal 110–240V with integrated voltage stabilizer.
  • Packaging: Inner thermocol/styrofoam and outer cardboard box for secure transport.
