VERTICAL TRIPLE WALLED WINGNUT AUTOCLAVE

VERTICAL TRIPLE WALLED WINGNUT AUTOCLAVE

VERTICAL TRIPLE WALLED WINGNUT AUTOCLAVE

Categories: ,

Model No: AGN-805
It is designed for high-efficiency sterilization with maximum user safety. It features an inner chamber, jacket, outer chamber, and support ring fully made of stainless steel. The heater’s cover stand and carrier/bucket are also stainless steel, while the lid is a thick machined stainless-steel plate with SS knobs for safe and secure locking.
Enquire Now

Share

Technical Specifications

  • Construction: Inner chamber, jacket, outer chamber, and support ring are fully made of stainless steel (SS 304).
  • Heater Cover & Carrier/Bucket: Made of stainless steel.
  • Lid: Thick machined stainless steel with SS knobs for safe and secure locking.
  • Safety Devices: Lid fitted with:
    • Pressure gauge
    • Spring-loaded safety valve
    • Double safety valve
    • Manual exhaust valve
    • Vacuum breaker
    • Water level indicator
  • Drain Valve: Facilitates easy chamber cleaning.
  • Gasket: Moulded, jointless silicon rubber gasket.
  • Welding: All internal joints are argon arc welded, ground, and polished for crevice-free internals.
  • Electrical Safety: Miniature circuit breaker for mains ON/OFF and control panel protection.
  • Energy Efficiency: Industrial-grade heaters reduce power consumption.
  • Accessories:
    • Water level indicator
    • Stainless steel basket
    • Vacuum breaker
Optional Features:
  • Semi-Automatic:
    • Automatic pressure control switch
    • Automatic low water cut-off system
    • Microprocessor-based digital temperature indicator/controller with set value, process valve, and digital timer
  • Fully Automatic:
    • Automatic low water cut-off system
    • Automatic pressure control switch
    • Control options: ON/OFF/T.P.
    • PT-100 pressure sensor for chamber
    • User-settable purging range and post-sterilization drying time
    • User-settable boiler control
    • High/Low alarm buzzer with process end indication
    • Pressure display
    • Inbuilt sterilization cycle process
Technical Specifications:
  • Working Pressure: 15–20 PSI
  • Working Temperature: 121–125°C
  • Power Supply: 220–230V AC, 50/60 Hz
  • Pressure Vessel: SS 304 grade stainless steel
  • Testing Pressure: 40 PSI
  • Top Lid: SS 304 grade stainless steel
  • External Wall: SS 304 grade stainless steel
  • Basket: High-grade stainless steel

Dimension (inch) 10 × 18 12 × 22 14 × 22 16 × 24 18 × 24 22 × 30
Inner Dimension (mm) 250 × 450 300 × 550 350 × 550 400 × 600 450 × 600 550 × 750
Capacity 22 Liters 40 Liters 50 Liters 78 Liters 98 Liters 180 Liters
Heater Load 1.5 KW 2 KW 3 KW 4 KW 4 KW 6 KW
