ROTARY EVAPORATOR

Categories: Laboratory Instruments, Rotary Evaporator

Model No: AGN-RE-01

Laboratory instrument used for the gentle and efficient removal of solvents from samples by evaporation under reduced pressure. It is ideal for applications in chemical, pharmaceutical, and biological laboratories. Equipped with an automatic electric lift, digital control of vapor temperature and rotation speed, and a precise water bath, it offers enhanced accuracy, repeatability, and ease of use. The system supports an adjustable speed range (10–275 rpm) and a temperature range up to 220°C, making it suitable for a wide range of distillation and concentration processes.

Shere

Technical Specifications

✅ Automatic Lifting Mechanism Effortless Height Adjustment with Electric Lift and Limit Position Detection (170 Mm Adjustment Range). ✅ Digital Precision Control

Digital Display of Vapor Temperature and Rotation Speed
Speed Range: 10 To 275 Rpm (Or better)
Microprocessor Controlled for Stability and Accuracy

✅ Advanced Water Bath System

Digital Display of Set & Actual Temperature
Temperature Range: Ambient To 220°C
Accuracy: ±2°C
Temperature Lock Feature for Process Safety
Infrared Communication with Vacuum Controller CE/CSA Certified

✅ Safety & Protection

Automatic Overheat Cut-Off
Separate Electronic Control for Bath Temperature, Vacuum, Vapor Temp & Rotation Speed

📦 Standard Scope of Supply ✔️ 1l Evaporating Flask ✔️ 1l Receiving Flask ✔️ Condensate Trap ✔️ Complete Vertical Glass Assembly ✔️ Digital Water Bath VACUUM CONTROLLER ✅ Key Features

User-Friendly Interface
Large Lcd Display with Intuitive Control Knob.
Integrated Solvent Database
Built-In Library Of 43 Solvents for Quick, Accurate Distillation Settings.
Automated Distillation
Unique Stage Probe Allows Smart Process Automation.
Vacuum Pump Control
Full-Speed Control Integrated for Safety and Optimization.

⚙️ Technical Specifications

Measuring Range: 1400 To 0 Mbar
Control Range: 1100 To 1 Mbar
Integrated Aeration Valve for Safe and Easy Release
Precision Pressure Sensor for Accurate Readings
Timer Function: Set Process Duration with Auto-Shutoff
Full Rotavapor Integration:
Lift/Lower Flask
Start/Stop Rotation
All Via the Vacuum Controller

VACUUM PUMP ✅ Key Features

High Flow Rate
Delivers 1.8 M³/H Or Better, Ensuring Fast and Reliable Performance Across Applications.
Ultimate Vacuum Performance
Achieves An Ultimate Vacuum Of 5 Mbar, Perfect for Demanding Lab and Industrial Settings.
Dual-Stage PTFE Diaphragm System
Equipped With 2-Stage Diaphragms Crafted From PTFE, Ensuring Chemical Resistance and Long-Term Durability.
Solvent Contamination Monitoring
Glass Inspection Windows Allow for Easy Visual Inspection of Diaphragms — Proactively Manage Solvent Build-Up and Contamination.
Noise & Vibration Reduction

RECIRCULATING CHILLER ✅ Key Features

Cooling Capacity: 530 Watts At 15°C
Temperature Range: -10°C To 25°C (Or better)
Tank Volume: 3 Liters (Or better)
Pump Capacity: 2.5 Liters/Min @ 0.6 Bar (Or better)
Coolant: Cfc-Free
Refrigerant: R-134a
