Ripple Tank Apparatus

Categories: Apparatus, Educational Equipments

Model No: AGN-1220

It is a versatile and specially designed setup for investigating fundamental wave properties, including propagation, reflection, refraction, diffraction, and interference. It can be conveniently used with an overhead projector for classroom demonstrations or as a free-standing bench model for direct investigations. The apparatus features a clear-bottom rectangular plastic tank with sloped sides to simulate a beach effect, eliminating unwanted reflections, and includes a complete range of accessories for comprehensive experiments.

Shere

Technical Specifications

Tank Design: Rectangular plastic tank with transparent bottom and sloped sides for beach effect to reduce reflections.
Support: Four detachable legs mounted at the underside corners; hole provided in the tray for easy water drainage.
Mountings:
- End clamps for supporting lamp holder.
- Pair of side clamps for mounting rippler support rods.
Rippler Assembly:
- Rectangular plastic rod with a series of holes for spherical dippers.
- Low-voltage DC motor with eccentric cam for oscillatory motion.
Accessories Supplied:
- Illuminant assembly.
- Set of 4 barriers: two larger L-shaped (75 × 25 mm) and two smaller L-shaped (25 × 25 mm).
- One curved barrier (2.5 cm high, uniform radius of curvature).
- One hand stroboscope.
- One convex lens and one concave lens.
- One rectangular block.
- Two spherical dippers.
- Spare elastic cords for suspending rippler assembly.
