RESEARCH TRINOCULAR MICROSCOPE

RESEARCH TRINOCULAR MICROSCOPE

Categories: ,

Model No: AGN-RTM-128
Magnification 40x
Model Number AGN-RTM-128
Brand AGN
Microscope Type Research Trinocular Microscope
Light Source LED
Is It Portable Portable
Illumination 3.5W LED Light (Up To 100,000 Working hours) with Intensity Controller.
Enquire Now

Shere

Technical Specifications

  • Optical System: Infinity optical system.
  • Stand: Sturdy, single-mould aluminium die-cast stand with anti-rust protection.
  • Viewing Head: Siedentopf trinocular head, 30° inclined, 360° rotatable, interpupillary distance (IPD) 48–75 mm, with diopter adjustment.
  • Eye Guards: Adjustable rubber eye guards for viewing comfort.
  • Eyepieces: Wide-field 10x eyepieces, F.O.V 20 mm, with ±5 diopter adjustment, anti-fungal and anti-reflective coated.
  • Nosepiece: Inward-facing quintuple revolving nosepiece with coded feature, click-stop mechanism, and rubber grip.
  • Objectives: Infinity plan objectives – 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 oil (SL).
  • Magnification Range: 40x to 1000x.
  • Mechanical Stage: Double-plate graduated stage (150 mm × 139 mm), X/Y travel 75 mm × 52 mm, rackless, scratch-resistant, with dual specimen holder clips.
  • Focusing: Coaxial coarse and fine focusing, fine adjustment scale value 0.002 mm.
  • Condenser: Movable Abbe condenser, N.A. 1.25, anti-fungal and anti-reflective with aspheric lens; iris diaphragm with frosted white/blue filter.
  • Illumination: 3.5 W LED (up to 100,000 hours) with intensity controller.
  • Display: LCD display for magnification, sleep mode, brightness indication, lock, and more.
  • Power Supply: Universal input 110–240 V with integrated voltage stabilizer.
  • Packaging: Inner thermocol/styrofoam with outer cardboard box for secure packing.
  • Applications: The Research Trinocular Microscope, when integrated with iPad connectivity, expands research and teaching potential. A demonstration video is available on YouTube showcasing its features and applications.
