Optical System: Finite optical system.
Stand: Rigid single-mould aluminium die-cast body with anti-rust coating for durability.
Viewing Head: Siedentopf binocular head, 30° inclined, 360° rotatable, interpupillary distance 48–75 mm with diopter adjustment.
Eye Guards: Adjustable rubber eye guards for comfortable viewing.
Eyepieces: Widefield 10x, F.O.V. 18 mm; optional 10x, F.O.V. 20 mm; antifungal and anti-reflection coated.
Nosepiece: Forward-facing quadruple revolving nosepiece with precise click-stop mechanism and rubber grip.
Magnification Range: 40x to 1000x.
Objectives: Plan achromatic 4x/0.10, 10x/0.25, 40x/0.65 (spring-loaded), 100x/1.25 oil (spring-loaded).
Mechanical Stage: Double-plate graduated stage, size 140 mm × 140 mm; X/Y travel range 90 mm × 65 mm; scratch-resistant surface with dual specimen holder clips.
Focusing: Coaxial coarse and fine focusing system; fine adjustment 0.2 mm/rotation.
Condenser: Movable Abbe condenser, N.A. 1.25 with aspheric lens; iris diaphragm with frosted white/blue filter; antifungal and anti-reflection coated.
Illumination: 3W LED illumination (up to 100,000 working hours) with adjustable intensity control.
Power Supply: Universal 110–240V AC input with built-in voltage stabilizer.
Packaging: Inner thermocol/styrofoam protection with outer cardboard box.
