Refrigerated Universal Centrifuge Brushless, Premium Model With Touch Screen

Model No: AGN-90CM
Advanced Benchtop Refrigerated Universal Centrifuge features a maintenance-free brushless motor, eliminating the need for carbon brushes for enhanced durability and quiet operation. The centrifuge achieves a maximum speed of 20,000 rpm when fitted with a 12 x 2 ml rotor, with speed varying according to the rotor used. It is equipped with a PLC-based colored touch screen display for intuitive, user-friendly operation and precise control.

Shere

Technical Specifications

  • Brushless Motor: Maintenance-free brushless motor without carbon brushes for reliable and quiet performance.
  • High Speed: Maximum speed of 20,000 rpm with 12 x 2 ml rotor; speed depends on rotor type.
  • PLC-Based Colored Touch Screen: Advanced, easy-to-use display showing countdown timer (1 to 99 minutes), digital RPM, and RCF meter with programmable speed control.
  • Programmable Speed Controller: Allows precise speed adjustments to meet diverse centrifugation protocols.
  • Automatic Rotor Identification: Enhances safety and convenience by automatically recognizing the rotor installed.
  • Temperature Control: Standby temperature range from -20°C to +40°C, controlled by a microprocessor-based digital temperature controller and indicator. Working temperature range from room temperature down to -20°C ensures optimal sample preservation.
  • Benchtop Design: Compact, ergonomic, and suitable for demanding laboratory environments.
Rotor Head Options for AGN-90CM (Extra Cost – Customer Selection Required)
Rotor Type Capacity Max Speed
4 Angle Rotor 12 x 1.5/2.2 ml with adapters 0.5/0.2 ml 20,000 rpm
4 Angle Rotor 24 x 1.5/2.2 ml 16,000 rpm
4 Angle Rotor 8 x 15 ml 13,000 rpm
4 Angle Rotor 6 x 50 ml 13,000 rpm
4 Angle Rotor 4 x 100 ml 13,000 rpm
4 Angle Rotor (PCR strip tubes) 4 strips of 8 x 0.2 ml (32 tubes) 13,000 rpm
4 Swing Out Rotor Head 8 x 15 ml 5,000 rpm
4 Swing Out Rotor Head 2 Plates of 96 wells 3,000 rpm
4 Swing Out Rotor Head 6 Plates of 96 wells 3,000 rpm
