MOTORIZED UPRIGHT METALLURGICAL MICROSCOPE FOR PRECISION ANALYSIS

MOTORIZED UPRIGHT METALLURGICAL MICROSCOPE FOR PRECISION ANALYSIS

MOTORIZED UPRIGHT METALLURGICAL MICROSCOPE FOR PRECISION ANALYSIS

<
INVERTED METALLURGICAL MICROSCOPE INVERTED METALLURGICAL MICROSCOPE
>
UPRIGHT METALLURGICAL MICROSCOPE UPRIGHT METALLURGICAL MICROSCOPE

Categories: ,

Model No: AGN-IMM-QX-3RT
Magnification 50x
Camera Resolution 20MP
Model Number AGN-IMM-QX-3RT
Brand AGN
Is It Portable Portable
Filter Blue, Green & Yellow
Observations Bright field, Analyser / Polarizer, DIC
Polarizing Polarizing And Analyser Slide In/out Of Optical Path
Mechanical Stage Coated Double Plate Graduated Stage Size 190mm X 240mm, X/Y Travel 75mm X 50mm
Enquire Now

Shere

Technical Specifications

  • Optical System: Infinity-corrected optical system for superior image clarity.
  • Stand: Robust aluminum die-cast body with anti-rust finish for durability.
  • Viewing Head: Sidentopf trinocular tilting head, inclined 0°–35°, rotatable 360°, interpupillary distance 48–75 mm, with diopter adjustment.
  • Eye Guards: Adjustable rubber eye guards for comfortable long-duration viewing.
  • Eyepieces: Wide-field 10X, F.O.V. 22 mm, crosshair reticule (0.1 mm), with diopter adjustment on both eyepieces.
  • Nosepiece: Sextuple revolving nosepiece with click-stop mechanism and slot for DIC attachment.
  • Objectives (Infinity Plan):
    • 5X / N.A. 0.15
    • 10X / N.A. 0.30
    • 20X / N.A. 0.45
    • 50X / N.A. 0.80
    • 100X / N.A. 0.90 (DIC compatible)
  • Magnification Range: 50X to 1000X.
  • Mechanical Stage: Double plate graduated stage (190 × 240 mm), X/Y travel 75 × 50 mm, scratch-resistant with double specimen holder clips.
  • Focusing: Coaxial coarse and fine focusing system with adjustable tension; fine focus precision 0.2 mm/rev.
  • Polarization: Built-in polarizer and analyzer slides, in/out of optical path.
  • Illumination:
    • Reflected 15W LED illumination with dimmer
    • Secondary 5W LED reflected light source with filters
  • Diaphragms: Adjustable aperture and field diaphragms (centerable).
  • Observation Modes: Brightfield, Polarizer/Analyzer, and DIC (Differential Interference Contrast).
  • Filters: Blue, Green, Yellow, and ND50 Neutral Density filter.
  • Power Supply: Universal 110–240V with integrated voltage flux stabilizer.
  • Packaging: Inner thermocol/styrofoam protective packing with outer reinforced cardboard box.
