Micrometer Slide Comparator

Product Description

The Micrometer Slide Comparator from AGN Enterprises is a precision optical laboratory instrument designed for measuring and comparing small linear dimensions and accurately determining the displacement of an object or image. It is commonly used in optics and physics laboratories for experiments requiring precise measurement with a micrometer arrangement. The instrument is suitable for schools, colleges, universities, engineering institutes, and research laboratories.

Micrometer Slide Comparator Features

AGN Enterprises manufactures the Micrometer Slide Comparator using precision-finished mechanical and optical components to provide smooth movement and reliable measurements. Moreover, the micrometer mechanism enables controlled linear displacement for accurate comparison and observation. The graduated scale and fine adjustment arrangement allow users to take precise readings during optical experiments. Furthermore, its robust construction supports repeated laboratory use while providing convenient handling and alignment.

Applications of Micrometer Slide Comparator

The instrument is suitable for experiments involving small displacement measurements, optical comparison, image measurement, focal length studies, and precision linear movement. In addition, it can be used with suitable optical arrangements for measuring minute changes and comparing dimensions accurately. Physics laboratories, optics laboratories, engineering colleges, universities, and research institutions use the instrument for practical measurement and experimental studies. Therefore, it provides a useful solution for precision measurement in educational and research laboratories.

Why Choose AGN Enterprises

AGN Enterprises manufactures every Micrometer Slide Comparator using carefully selected materials and precision mechanical components. Our engineers inspect each unit before dispatch to ensure smooth operation, reliable measurement, and consistent experimental performance. Besides offering durable laboratory construction, we provide competitive pricing, customization options, prompt delivery, and responsive technical support. Finally, AGN Enterprises supplies dependable physics and optics laboratory equipment for educational institutions, research organizations, and technical training centers.

• Measuring Range: Direct measurement up to 50 mm in steps of 0.01 mm (0.001 cm) using a large micrometer head.
• Construction:
  • Reading microscope screw, drumhead, and stage mounted on a robust base inclined at 45° for comfortable observation.
  • Stage size: 7.5 × 15 cm, fitted with spring clips to hold samples securely.
• Micrometer Slide:
  • Moves along a lifeline stainless steel scale.
  • Movements read directly on a large drum head to 0.01 mm (or 0.001 cm via attached vernier).
  • Micrometer screw and nut are specially aged and normalised for long-term accuracy.
  • Total movement range: 50 mm.
• Optics: Reading microscope with rack and pinion focusing; fitted with highly achromatic optics for clarity.
• Additional Features:
  • Extra support leg for bringing the instrument to a horizontal reading position.
  • Substage mirror in gimbals for efficient light reflection.
  • Complete in a polished wooden case for safe storage and transport.
