Laminar Air Flow Workstation (VERTICAL)

Laminar Air Flow Workstation (VERTICAL)

Laminar Air Flow Workstation (VERTICAL)

Categories: ,

Model No: AGN-156
Vertical Laminar Air Flow Workstation is a high-performance sterile environment unit, designed to meet the needs of modern laboratories requiring protection for samples and processes. Constructed with a durable mild steel/ stainless steel body duly powder-coated, it ensures a long service life and resistance to corrosion. The workbench is made of high-grade 304 stainless steel perforated sheet, which enhances airflow and provides a clean, sterile work surface.
Enquire Now

Share

Technical Specifications

  • Construction:
    • Outer body made of mild steel, finished with durable powder coating.
    • Workbench made of 304-grade stainless steel perforated sheet for hygienic and corrosion-resistant surface.
  • Air Flow System:
    • Vertical laminar airflow for top-down sterile air distribution.
    • High-efficiency particulate air (HEPA) filter typically rated at 99.97% efficiency at 0.3 microns (specification may vary by model).
  • Control & Monitoring:
    • Microprocessor control system with Touch Panel LCD Display.
    • Digital manometer for pressure monitoring.
    • Filter failure alarm for timely maintenance and safety assurance.
  • Lighting & Safety:
    • LED white light for clear visibility.
    • UV germicidal light for disinfection (with micro switch to automatically turn off UV when door is open).
    • Motorized vertical glass door for smooth, touch-free operation.
  • Additional Utilities:
    • Gas cock for Bunsen burner or gas-based utilities.
    • Internal 15/5 amp socket for powering lab equipment.
  • User-Friendly Features:
    • Soft-touch switches for blower, UV light, and other functions.
    • Quiet operation with low vibration levels for sensitive procedures.
Model No. Product Name Construction Material Dimensions (W x D x H)
AGN-156-A Laminar Air Flow Workstation (Vertical) – Mild Steel Mild Steel, Powder Coated 60 x 60 x 60 cm
AGN-156-B Laminar Air Flow Workstation (Vertical) – Mild Steel Mild Steel, Powder Coated 90 x 60 x 60 cm
AGN-156-C Laminar Air Flow Workstation (Vertical) – Mild Steel Mild Steel, Powder Coated 120 x 60 x 60 cm
AGN-156-D Laminar Air Flow Workstation (Vertical) – Mild Steel Mild Steel, Powder Coated 150 x 60 x 60 cm
AGN-156-E Laminar Air Flow Workstation (Vertical) – Stainless Steel 304 Grade Stainless Steel 60 x 60 x 60 cm
AGN-156-F Laminar Air Flow Workstation (Vertical) – Stainless Steel 304 Grade Stainless Steel 90 x 60 x 60 cm
AGN-156-G Laminar Air Flow Workstation (Vertical) – Stainless Steel 304 Grade Stainless Steel 120 x 60 x 60 cm
AGN-156-H Laminar Air Flow Workstation (Vertical) – Stainless Steel 304 Grade Stainless Steel 150 x 60 x 60 cm
