HORIZONTAL RECTANGULAR SQUARE BODY AUTOCLAVE FULLY AUTOMATIC

Categories: Autoclave, Laboratory Instruments

Model No: AGN-813

It is a robust sterilization unit designed for high-efficiency laboratory and industrial applications. Its inner chamber, outer chamber, and support ring are fully constructed from stainless steel, ensuring durability and long-term reliability. The lid, made of thick machined stainless steel, features a radial locking system for user safety. All internal joints are argon arc welded, ground, and polished, providing a crevice-free, hygienic interior. The autoclave includes industrial-grade energy-efficient heaters to reduce power consumption and a miniature circuit breaker for control panel safety.

Shere

Technical Specifications

Full SS construction – inner chamber, outer chamber, support ring, heater cover stand, and carrier/bucket.
Radial locking lid for safe closure.
Lid equipped with:
- Pressure gauge
- Spring-loaded safety valve
- Double safety valve
- Manual exhaust valve
- Vacuum breaker
- Water level indicator
Drain valve for easy chamber cleaning.
Jointless silicon rubber gasket for perfect sealing.
Energy-efficient industrial heaters.
Miniature circuit breaker for mains on/off.
PLC and HMI-based control with jumbo LCD 20×4 display.
Automatic self-locking system.
Fully automatic PID purging system.

Display & Control Features:

ON/OFF / T.P. control
PT-100 sensors for boiler and chamber
Pressure sensor for chamber
User-settable purging range, sterilization time, post-sterilization drying time, and boiler control
Buzzer alerts for high/low alarms and process end
Pressure display with transmitter
Inlet for HEPA filter
Inbuilt sterilization cycle process

Standard Accessories:

Water level indicator
Vacuum breaker
Automatic pressure cut-off switch
Automatic low water cut-off switch
Digital temperature indicator cum controller with timer
Moisture trap

Technical Specifications:

Gasket: Jointless silicon rubber
Exhaust Pressure: Manual through exhaust valve
Sterilizing Pressure: 1.2–1.5 kgf/cm² (15–20 psi) at 121°C
Operating Pressure: 15–35 psi
Pressure Gauge: 0–2.1 kgf/cm² (up to 60 psi)
Pressure Vessel: SS 304 Grade Stainless Steel
External Wall: SS 304 Grade Stainless Steel
Top Lid: SS 304 High-Grade Stainless Steel
Basket: High-Grade Stainless Steel

Dimension (inch)	18×18×36	18×24×36	24×24×30	24×24×48	36×36×60	36×36×72
Inner Dimension (mm)	450×450×900	450×600×900	600×600×900	600×600×1200	900×900×1500	900×900×1800
Capacity	180 Liters	240 Liters	320 Liters	430 Liters	1300 Liters	1500 Liters
Heater Load	12 kW	18 kW	18 kW	18 kW	36 kW	48 kW
