It is an instrument used in research, histology, and pathology for rapid and precise sectioning of biological tissues at low temperatures.

Instrument type: Freestanding cryostat with an encapsulated, splash-proof rotary microtome
Microtome type: Fully automatic microtome
Microtome operation: Electronically controlled, motorized system
Coarse feed speed: Slow – 300 μm/s in 20 μm steps; Fast – 900 μm/s
Maximum specimen size: 55 × 55 mm
Sectioning method: Manual as well as motorized automatic section cutting
Handwheel provision: Mechanical handwheel
Chamber illumination: Bright white LED light
Chamber cooling temperature: Up to −35 ± °C
Specimen cooling temperature: −45 ± 5 °C
Section thickness range:
- 0–5.0 μm in 0.5 μm increments
- 0–20.0 μm in 1.0 μm increments
- 0–60.0 μm in 5.0 μm increments
- 0–100.0 μm in 10.0 μm increments
Vertical stroke length: 60 ± 2 mm
Horizontal feed range: 26 ± 2 mm
Defrost cycle duration: Approximately 10 minutes
Power supply: 230 V, 50 Hz, single phase
