DIGITAL STEREO ZOOM MICROSCOPE

DIGITAL STEREO ZOOM MICROSCOPE

DIGITAL STEREO ZOOM MICROSCOPE

Categories: ,

Model No: AGN-DSZM-06
Display 12.2″ TFT, IPS Touch Screen, 360˚ Rotatable
Camera Built in Camera with ULTRACAM 5.0 MP Resolution
Model NumberAGN-DSZM-06
BrandAGN
Software Pre-loaded Capture and Measurement Software
Viewing BodyIntegrated Binocular/Trinocular head
Magnification Range7x to 45x continuous
Enquire Now

Share

Technical Specifications

Exclusive Screen Features
  • Display: 12.2″ TFT, IPS Touch Screen, 360˚ Rotatable
  • Camera: Built-in ULTRACAM, 5.0 MP Resolution
  • Software: Pre-loaded Capture & Measurement Software
  • Connectivity: Bluetooth 4.0
  • Battery: Li-ion Battery, Up to 8 Hours Backup
  • Operating System: Windows 10 Home
  • Memory: 4GB RAM, 64GB eMMC + 64GB microSD Card
  • I/O Ports: USB 3.0 × 1, Mini-HDMI × 1, microSD Slot × 1
Technical Specifications
  • Optical System: Greenough
  • Zoom Ratio: 1:6.4
  • Viewing Body: Integrated Binocular/Trinocular Head, 45° Inclined, Interpupillary Distance 50–75mm Adjustable
  • Working Distance: 110mm
  • Magnification Range: 7x to 45x (Continuous)
  • Eyepieces: Paired 10x, Wide Field, 20mm FOV
  • Eye Guards: Retractable Rubber Type
  • Illumination Control: 3.3W Incident / Transmitted (Oblique Setting) / Combined Illumination with Rheostat Dial for Intensity Control
  • Incident Light: 3.3W – 30° Oblique Illumination with Variable Intensity Control
  • LED Service Life: ~25,000 Hours
  • Light Quality: Homogeneous Daylight (6500°K), UV & IR Free
  • Power Supply: Universal 100V–240V, 50/60Hz with Integrated Voltage Stabilizer
Package Contents
  • Power Cable (6 ft)
  • Nylon Dust Cover & Cleaning Cloth
  • Protective Styrofoam Casing
  • Warranty Card
Optional Accessories
  • Pointers & Micrometer Reticules
  • Polarizing Kit
  • Auxiliary Objectives: 0.5x, 0.75x, 1.5x & 2x
  • Wide Field Eyepieces: 20x & 25x
  • Dark Field Kit with Gem Tweezer
  • Camera Attachments (0.35MP – 14MP)
  • Image Analysis Software
  • CFL & LED Ring Light
Wooden Storage Box

Related Products

AGN-90CM refrigerated centrifuge with digital speed and temperature control
