Digital Probe Sonicator

‹ Digital Potentiometer with Inbuilt Stirrer › Digital Probe Sonicator

Categories: Analytical Equipments, Probe Sonicator

Model No: AGN-3510

They are frequency tracking with adjustable power and amplitude from 0–100%. Operates at a sonotrode frequency of 20 kHz. The control panel displays time settings and operational data, with flexible working modes ranging from 1 second to 99 hours, including continuous operation with pause function. Equipped with built-in generator protection against overload, overheating, and short circuits, along with a soft-start system. Rated power is 750 W with input voltage options of 110 V or 220–240 V and input frequency of 50–60 Hz. Maximum output power is ≤750 W. The sonotrode can withstand temperatures up to 100°C and pressure up to 5 MPa. Suitable for liquid treatment volumes ranging from 0.5 ml to 500 ml.

Technical Specifications

Digital Probe Sonicator with automatic frequency tracking
Power and amplitude adjustable from 0–100%
Sonotrode operating frequency: 20 kHz
Operation panel displays time settings and working parameters
Working modes: 1 second to 99 hours with pause function or continuous operation
Built-in generator protection against overload, over-temperature, and short circuit, with soft-start feature
Rated power: 750 W; maximum output power ≤750 W
Input voltage: 110 V / 220–240 V; input frequency: 50–60 Hz
Maximum sonotrode temperature: 100 °C
Maximum operating pressure: 5 MPa
Liquid processing capacity: 0.5 mL to 500 mL
