Bomb Calorimeter >

Automatic Bomb Calorimeter

Automatic Bomb Calorimeter

[product_navigation]
Model No: AGN 1160
Features a 128×64 graphical LCD with temperature resolution of 0.0010°C. Stores up to 1000 logs with date and time, and includes a USB interface for PC connectivity. Equipped with an inbuilt thermal printer and real-time clock with battery backup. Capable of measuring and calculating calorific value and water equivalent, with full test report printouts via the integrated printer. Sample weight, water equivalent, and sensitivity can be configured directly from the keypad on a single screen. Includes fuse wire open indication, no-paper or printer door detection, and audio alerts during firing and post-test. Automatically detects temperature rise and fall. Operates on 230V ±10% / 50 Hz AC and supplied complete with all necessary accessories.

Share

Technical Specifications

  • Automatic Bomb Calorimeter, microprocessor-based with 128 × 64 graphical LCD display
  • Temperature resolution: 0.0010 °C
  • Internal memory stores up to 1000 logs with date and time
  • USB interface for PC connectivity and data transfer
  • Inbuilt thermal printer for full test report printouts
  • Real-time clock with battery backup
  • Measures and calculates calorific value and water equivalent
  • Sample weight, water equivalent, and sensitivity adjustable via keypad on a single page
  • Fuse wire open indication with adjustable error detection
  • Detects paper/printer door status automatically
  • Audio indications on ignition and after test completion
  • Automatic detection of temperature rise and fall
  • Power supply: 230 V ±10%, 50 Hz AC
  • Supplied complete with all necessary accessories
