VERTICAL DOUBLE WALLED SQUARE BODY AUTOCLAVE FULLY AUTOMATIC

VERTICAL DOUBLE WALLED SQUARE BODY AUTOCLAVE FULLY AUTOMATIC

VERTICAL DOUBLE WALLED SQUARE BODY AUTOCLAVE FULLY AUTOMATIC

Categories: ,

Model No: AGN-808
It is a fully automatic sterilizer designed for efficient and reliable sterilization of laboratory instruments, glassware, and media. Its robust stainless-steel construction ensures long-term durability, safety, and superior performance.
Enquire Now

Share

Technical Specifications

  • Inner chamber, outer chamber, and support ring made of SS 304 stainless steel.
  • Heater cover stand and carrier/basket made of stainless steel.
  • Thick machined stainless-steel lid with radial locking system for maximum safety.
  • Lid fitted with pressure gauge, spring-loaded safety valve, double safety valve, manual exhaust valve, vacuum breaker, and water level indicator.
  • Drain valve for easy cleaning of the chamber.
  • Moulded jointless silicon rubber gasket for a perfect seal.
  • Argon arc welded joints, ground and polished for crevice-free interiors.
  • Miniature circuit breaker (MCB) for mains on/off and control panel safety.
  • Energy-efficient industrial-grade heaters reduce power consumption.
  • Automatic pressure control switch and low water cut-off switch.
  • Fully automatic PID-based purging system for precise control.
Includes:
  • Water Level Indicator
  • Stainless Steel Basket
  • Vacuum Breaker
  Technical Specifications:
  • Gasket: Jointless silicon rubber
  • Sterilizing Pressure: 1.2 to 2.5 kgf/cm² (15–35 psi)
  • Temperature Range: 121°C to 134°C
  • Operating Pressure: 15 psi to 35 psi
  • Pressure Gauge: 0–2.1 kgf/cm² (up to 60 psi)
  • Pressure Vessel: SS 304 Grade Stainless Steel
  • External Wall: SS 304 Grade Stainless Steel
  • Tray: SS 304 High Grade Stainless Steel
  • Basket: High Grade Stainless Steel
  • Stand and Support Ring: SS 304 Grade Stainless Steel

Dimension (inch) 10 x 18 12 x 22 14 x 22 16 x 24 18 x 24 22 x 30
Inner Dimension (mm) 250 x 450 300 x 550 350 x 550 400 x 600 450 x 600 550 x 750
Capacity 22 Liters 40 Liters 50 Liters 78 Liters 98 Liters 180 Liters
Heater Load 1.5 KW 2 KW 3 KW 4 KW 4 KW 6 KW
