VACUUM OVEN

VACUUM OVEN

VACUUM OVEN

Categories: ,

Model No: AGN-106
Vacuum oven is used for drying, heating, or curing materials in a controlled, low-pressure environment. It minimizes oxidation and thermal degradation, making it suitable for delicate or heat-sensitive substances. Built with a stainless steel inner chamber and insulated walls, it ensures even heat distribution. The system includes a PID temperature controller, vacuum and gas inlet valves, and operates on 230V AC.
Enquire Now

Share

Technical Specifications

  • Double-wall construction for enhanced insulation.
  • Inner chamber: Polished 304 stainless steel.
  • Outer body: Mild steel with epoxy powder coating.
  • 75mm thick high-grade glass wool insulation.
  • Uniform heating via gentle heating elements.
  • PID microprocessor controller with ±1°C accuracy.
  • PT-100 sensor for precise temperature detection.
  • Two valves: one for 760 mm Hg vacuum, one for inert gas inlet.
  • Door made of SS 304/M.S with glass window.
  • Operates on 230V ±10%, 50Hz power supply.

Model No. Chamber Type Inner size No of Tray. Capacity Temperature Range
AGN-106(A) Cylindrical 300×300 mm 1 Nos. 24L 50°-150°C
AGN-106(B) Cylindrical 300×500 mm 2 Nos. 40L 50°-150°C
AGN-106(C) Rectangular 350x350x350 mm 2 Nos. 45L 50°-150°C
AGN-106(D) Rectangular 450x450x450 mm 2 Nos. 95L 50°-150°C
AGN-106(E) Rectangular 600x600x600 mm 2 Nos. 224L 50°-150°C
Optional:
  1. PLC Controller with 21 CFR Software and data recorder
  2. Radial lock door for cylindrical Vacuum Oven
  3. Vacuum Pump
