TRINOCULAR PETROLOGICAL MICROSCOPE

TRINOCULAR PETROLOGICAL MICROSCOPE

[product_navigation]

Categories: Microscopes, Polarizing Microscopes

Model No: AGN-PQR- 500 IM

Magnification Range	50X to 500X.
Model Number	AGN-PQR- 500 IM
Brand	AGN
Is It Portable	Portable
Mechanical Stage	160mm
Power	Universal Power Supply 110v-240v
Focusing	Co-axial Coarse And, Fine Adjustment 0.2mm/Rotation

Share

Technical Specifications

Optical System:

High-contrast, infinity-corrected optical system

Stand:

Aluminum die-cast, anti-rust construction for durability

Viewing Head:

Trinocular, inclined at 30°
360° rotatable
Interpupillary distance (IPD): 48–75 mm
Diopter adjustment for precise focusing

Eye Guards:

Adjustable rubber eye guards for comfortable viewing

Eyepieces:

Wide-field 10x, FOV 22 mm
Anti-fungal and anti-reflection coated

Intermediate Tube:

Built-in focusable Bertrand lens, removable from optical path

Nosepiece:

Inward quadruple/quintuple revolving nosepiece
Click stops and centrable mechanism
Rubber grip for ease of use

Objectives:

Infinity-corrected objectives: 5x (NA 0.15), 10x (NA 0.30), 20x (NA 0.45), 50x (NA 0.80), optional 100x
Magnification range: 50x–500x

Mechanical Stage:

Graduated circular stage, 160 mm diameter

Focusing:

Co-axial coarse and fine focusing
Fine adjustment: 0.2 mm per rotation

Condenser:

Movable Abbe condenser, NA 1.25 with aspheric lens
Rack-and-pinion movement with centering device

Illumination:

3W LED light, up to 100,000 working hours
Intensity controller
Separate attachment for reflected light

Filters:

Blue, green, and yellow

Observation Modes:

Bright field and analyzer-polarizer

Power Supply:

Universal 110–240V with integrated voltage fluctuation stabilizer

Packaging:

Inner thermocol/styrofoam packing
Outer cardboard box
