Torsion Apparatus Searle’s Horizontal Pattern Half Meter Long

Categories: Educational Equipments

Model No: AGN-2422

Two cast iron feets each with 3 through holes and grub securing screws, separating by two support rods approx 600mm long one of which is graduated in cm and mm. The wheel 165mm dia. over groove moving on ball bearings is provided with chuck to hold the test rod of 55cm long and 5mm dia with two aluminum scales graduated 30-0-30 in single degrees, mounted on pillar support, which are adjustable along the rod, two pointers with clamp for attaching to specimen, on each of brass and steel rods, cord and hook for carrying masses. Supplied without weights.

Shere

Technical Specifications

Base & Support:
- Two cast iron feet, each with three through holes and grub securing screws.
- Feet separated by two support rods (~600 mm long), one of which is graduated in cm and mm.
Rotating Wheel:
- Diameter: 165 mm with an over-groove moving on ball bearings.
- Equipped with a chuck to hold the test rod (55 cm long, 5 mm diameter).
Angular Measurement:
- Two aluminum scales graduated 30–0–30°, mounted on pillar supports.
- Scales are adjustable along the rod.
- Two pointers with clamps for attaching to the specimen (applicable to both brass and steel rods).
Accessories for Torsion Experiment:
- Cord and hook for applying masses to generate torque.
- Supplied without weights.
