Categories: Microscopes, Stereo Zoom Microscopes

Model No: AGN-SZM-2D/3D

Magnification	5x
Model Number	AGN-SZM-2D/3D
Brand	AGN
Is It Portable	Non-Portable
Magnifications	0.7x to 5.0x Continuous.
Working Distance	86mm
Focusing	Continues Zoom Focus
Zoom Ratio	1 : 7
Illumination	3W Ring LED Light with Intensity Control & On/Off Switch

Share

Technical Specifications

Specifications

Optical System: Greenough design.
Stand: Ergonomically designed metal pole stand.
Lens: Zoom lens with optional 3D objective attachment; antifungal treatment and anti-reflection coated.
Magnification Range: Continuous 0.7x to 5.0x.
Zoom Ratio: 1:7.
Working Distance: 86 mm.
Focusing: Continuous zoom focus.
Illumination: 3 W ring LED with adjustable intensity and on/off switch.

Camera Specifications

Mount: Standard C-mount (aluminum)
Sensor: SONY HD CMOS, 1/2.3 inch, 2.2 μm pixel size
Preview/Resolution: 1920 × 1080
Still Capture Resolution: 4608 × 3456
Video Resolution: 1920 × 1080, 30 fps (SD Card/USB/HDMI)
Recording Media: SD Card (4 GB)
Exposure: 1/1000 – 10 s, automatic/manual
Settings: Gain, gamma, saturation, contrast
White Balance: Automatic/manual
Interfaces: USB 2.0, HDMI
Software: AMCAP
Compatible OS: Windows XP/7/8/10 (32/64-bit)
Power Supply: DC 12V 2A; AC adapter input 100–240 V, DC output 12V/5A/60W
Operating Conditions: 0–60°C, 45–85% humidity
Storage Conditions: -20–70°C
Dimensions: 52 × 52 × 56 mm
Weight: 550 g

Packaging

Inner thermocol/styrofoam protection and outer cardboard box.
