Single Still Water Still with Silica Sheathed Heater

Single Still Water Still with Silica Sheathed Heater

Single Still Water Still with Silica Sheathed Heater

Categories: ,

Model No: AGN.3549
Water Stills are precisely engineered to produce high-purity, pyrogen-free distilled water. The Borosilicate Glass Water Still features a horizontal-type boiler, condenser, constant level device, silica-sheathed (quartz) heater, and comes complete with stand and clamps. All components are replaceable.
  • Conductivity range: 1–2 µS/cm.
  • pH range: 5.5–6.0.
Enquire Now

Share

Technical Specifications

Key Features:
  • Compact and space-saving design.
  • Borosilicate condenser and boiler fitted with a removable silica-sheathed heater and screw-threaded connectors for easy cleaning and scale removal.
  • Efficient condenser ensures distillate temperature between 25°C and 45°C.
  • Powder-coated stand offers rust-free operation and a durable, attractive finish.
  • Automatic shut-off protects glass parts by stopping operation if the water level in the boiler drops below the heater.
  • Energy-saving design recirculates cooling water from the condenser back into the boiling chamber.
  • Boiler equipped with a replaceable side-overflow for easy draining and cleaning, minimizing the risk of breakage.
  • Safety fuse protects against voltage fluctuations and short circuits.
  • Electrical Power: 220/240V, 50/60Hz, Single Phase.
  • Unique Safety Feature: Built-in cut-off device safeguards the glass in case of water supply failure or overheating.

Cat. No. Output (Ltr./Hr.) Cooling Water Consumption (Ltr./Hr.) Power Rating (kW)
AGN.3549.01 1.5 40 1.5
AGN.3549.02 2.5 60 1.7
AGN.3549.03 4.0 120 3.0
