SINGLE LEVER AUTOCLAVE

SINGLE LEVER AUTOCLAVE

SINGLE LEVER AUTOCLAVE

Categories: ,

Model No: AGN-809
It is a high-performance sterilization unit designed for sterilizing laboratory glassware, plastic tubing, liquids in sealed glass containers, and other lab materials. Its unique single-lever locking system ensures effortless door operation and perfect sealing without leakage of vacuum or pressure. The unit’s double-walled construction and argon-welded joints ensure durability, efficiency, and complete safety during operation.
Enquire Now

Share

Technical Specifications

  • Fully automatic operation – the entire sterilization cycle starts with a single press of the start switch.
  • Double-walled construction – inner chamber made of stainless steel and outer body powder-coated for durability.
  • Fully argon welded to prevent steam and pressure leaks.
  • Single lever lock for easy lid lifting and secure closure.
  • Microprocessor-based PID temperature controller with dual digital indicator and PT-100 sensor for precise temperature control.
  • Automatic steam and air exhaust at the end of the cycle.
  • Specially designed heaters reduce power consumption.
  • Removable SS 304 rod-type basket for convenience and hygiene.
  • Low water level alarm and heater cut-off safety feature.
  • Lid equipped with pressure gauge (0–20 PSI), safety valve, and exhaust valve.
  • Vacuum breaker and steam release valve for enhanced safety.
Technical Parameters:
  • Temperature Range: 121°C to 135°C
  • Temperature Accuracy: ±1°C
  • Pressure Range: 0–21 PSI or 0–30 PSI
  • Pressure Accuracy: ±1.2 PSI
Optional Features:
  • Printer Output Facility – records PV, SV, actual date/time, with variable printer time intervals, 5000-line memory, and audio alarm on memory full.
  • Audio Alarm – alerts in case of temperature overshoot or undershoot.
  • 21 CFR Part 11 Compliance Software – for secure data management with FO value calculation.
  • Temperature Scanner – with two temperature probes to monitor and record internal temperature, including printing facility.
  • Digital Pressure Indication for enhanced monitoring.

Dimension (inch)10×1812×2214×2216×2418×2822×30
Inner Dimension (mm)250×450300×550350×550400×600450×710550×750
Overall Capacity30 Ltr43 Ltr64 Ltr91 Ltr135 Ltr212 Ltr
Working Capacity22 Ltr35 Ltr53 Ltr75 Ltr113 Ltr180 Ltr
Load1.5 kW2.0 kW3.0 kW4.0 kW4.0 kW6.0 kW
