The Roller Bottle Incubator is a specialized laboratory equipment designed for controlled incubation of roller bottles used in cell culture and related biological applications. It provides a controlled environment for maintaining suitable temperature conditions while roller bottles rotate continuously or at a controlled speed.
The incubator supports the cultivation of cells on the inner surface of roller bottles by providing gentle and uniform rotation. This increases the available surface area for cell growth and is particularly useful for applications requiring larger culture surfaces compared with conventional stationary culture vessels.| Parameter | Specification |
|---|---|
| Capacity | 175 Litres |
| Temperature Range | 5°C to 70°C |
| Temperature Increment | 0.1°C |
| Temperature Accuracy | ±0.5°C |
| Temperature Control | Peltier-based system with fan-assisted air circulation |
| Safety Features | Over-temperature protection (±2.0°C of set value) with audio-visual alarm |
| Display | Digital display for temperature and time |
| External Dimensions (W × H × D) | 600 × 900 × 700 mm |
| Internal Dimensions (W × H × D) | 450 × 700 × 525 mm |
| Control System | Microprocessor-controlled operating panel |
| Programmable Storage | Provision for storing ≥5 programs |
| Viewing Window | Outer glass window or inner glass door for sample observation |
| Construction | Inner chamber made of 304-grade stainless steel with rounded corners |
| Shelving | 3 removable stainless-steel shelves |
| Door Design | 180° wide-opening door for easy access |
| Utility Socket | 5A and 15A electrical sockets inside the chamber |
| Communication Port | RS-232 interface for data connectivity |
| Stabilizer | 5 kVA servo stabilizer supplied with 2 years warranty |
| Certification | CE and ISO Certified |
Compatible Roller Apparatus:
AGN Enterprises offers laboratory, scientific, healthcare, and research equipment for universities, research laboratories, pharmaceutical laboratories, biotechnology laboratories, medical institutions, and industrial R&D facilities.
The Roller Bottle Incubator is designed to support practical and research-oriented cell culture applications where controlled incubation and continuous bottle rotation are required.
