RESEARCH TRINOCULAR MICROSCOPE

RESEARCH TRINOCULAR MICROSCOPE

RESEARCH TRINOCULAR MICROSCOPE

<
RESEARCH BINOCULAR MICROSCOPE RESEARCH BINOCULAR MICROSCOPE
>
RESEARCH TRINOCULAR MICROSCOPE RESEARCH TRINOCULAR MICROSCOPE

Categories: ,

Model No: AGN-RTM-04T
Magnification 1000x
Is It Portable Non-Portable
Model Number AGN-RTM-04T
Brand AGN
Focusing Co-axial Coarse And Fine Focusing With 0.2mm/rotation.
Power 220V
Mechanical Stage 140mm x 140mm
Weight 5KG
Condenser Movable Abbe Condenser
Eyepieces Wide Field 10x, F.O.V 18mm & 10x, F.O.V 20mm
Objectives Plan Achromatic 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 Oil (SL).
Enquire Now

Shere

Technical Specifications

  • Optical System: Finite optical system.
  • Stand: One-piece robust aluminium die-cast body with anti-rust finish.
  • Viewing Head: Siedentopf trinocular head, 30° inclined, 360° rotatable; interpupillary distance 48–75 mm with diopter adjustment.
  • Eye Guards: Flexible, adjustable rubber eye guards for enhanced comfort.
  • Eyepieces: Widefield 10x, F.O.V. 18 mm; optional 10x, F.O.V. 20 mm; antifungal and anti-reflection coated.
  • Nosepiece: Forward-facing quadruple revolving nosepiece with precise click-stop mechanism and rubber grip.
  • Magnification Range: 40x to 1000x.
  • Objectives: Plan achromatic 4x/0.10, 10x/0.25, 40x/0.65 (spring-loaded), 100x/1.25 oil (spring-loaded).
  • Mechanical Stage: Double-plate graduated stage, 140 mm × 140 mm; X/Y travel range 90 mm × 65 mm; scratch-resistant surface with dual specimen holder clips.
  • Focusing: Coaxial coarse and fine focusing system with fine adjustment sensitivity of 0.2 mm/rotation.
  • Condenser: Movable Abbe condenser, N.A. 1.25 with aspheric lens; iris diaphragm with frosted white/blue filter; antifungal and anti-reflection coated.
  • Illumination: 3W LED light source (up to 100,000 working hours) with adjustable brightness control.
  • Power Supply: Universal input 110–240V AC with integrated voltage stabilizer.
  • Packaging: Secured with inner thermocol/styrofoam and outer cardboard box for safe transport.
