PCR Thermal Cycler Touch Screen

Categories: PCR Thermal Cycler, Pharmaceutical Equipments

Model No: AGN-2400

A 96 × 0.2 ml gradient thermal cycler equipped with an adjustable-pressure heated lid to prevent evaporation and condensation. Features long-life Peltier elements with a ramping rate of up to 5 °C/s and supports over 1,000,000 cycle operations. Powered by an Android system with a 5-inch large color touchscreen, integrated gradient function, built-in Wi-Fi module, large internal storage, and USB support. Offers precise time increments from 1 to 600 seconds and temperature increments from 0.1 to 10.0 °C.

Shere

Technical Specifications

PCR Gradient Thermal Cycler with touch screen interface
96 × 0.2 mL block capacity with adjustable pressure hot lid to prevent evaporation and condensation
Long-life Peltier elements for reliable performance
Fast ramping rate up to 5 °C/s; supports more than 1,000,000 cycle operations
Android-based system with 5-inch large color touch screen
Gradient function with temperature setting range of 30–99 °C
Built-in Wi-Fi module, large internal storage, and USB device support
Time increment range: 1 second to 600 seconds
Temperature increment range: 0.1 °C to 10.0 °C
Unique left-right separation design for amplification area and operating area
Temperature range: 4 °C to 105 °C
Maximum heating rate: ≥2.5 °C/s; maximum cooling rate: ≤2.5 °C/s
Temperature display accuracy: ±0.1 °C
Designed to perform up to 20,000 non-breakdown operations
Maximum programmable cycle number: 100
