Owen’s Bridge

Owen’s Bridge

Owen’s Bridge

<
Compass Box (Permanent Magnet) Compass Box (Permanent Magnet)
>
Hay’s Bridge Hay's Bridge

Categories: ,

Model No: AGN-1109
It is a precision electrical instrument used to measure the unknown value of inductance. The instrument is housed in a sturdy teak wood case and incorporates essential components to facilitate accurate measurements and ease of understanding for students and technicians.
Enquire Now

Shere

Technical Specifications

  1. AC Source:
    • Provides a 1 kHz sine wave signal.
    • Amplitude is indicated using a lamp on the bakelite board.
    • Two output sockets are provided for connecting the AC signal to external circuits.
  2. Detector:
    • Equipped with an in-built null detector for detecting small AC signals.
    • Includes a digital display for precise readings.
  3. Circuit Layout:
    • The circuit diagram is spread out clearly on the board to facilitate convenient working and understanding.
    • 4 mm sockets are provided for making all necessary connections easily.
  4. Resistance and Capacitance Dials:
    • R3: Decade dial with ranges ×10, ×100, ×1000 ohms.
    • R2: Decade dial of ×100 ohms.
    • C3, C4: Decade dial of ×0.1 μF.
    • R1: Internally fixed resistance of 1000 ohms.
