ORBITAL SHAKING INCUBATOR

Model No. AGN-110
Orbital Shaking Incubator is a temperature-controlled device designed for uniform mixing and incubation of samples. It features a stainless steel inner chamber, digital PID temperature controled, adjustable shaking speed (40–240 RPM), and a 200 mm orbital motion. Equipped with dual air circulation fans, glass wool insulation, and a PT-100 sensor, it ensures precise temperature regulation and consistent sample agitation, ideal for biological and chemical applications.

Shere

Technical Specifications

  • Constructed with a double-wall design for enhanced insulation.
  • Inner chamber made from mirror-finished SS 304 stainless steel.
  • Outer body built from mild steel, coated with durable epoxy powder.
  • Thermal insulation using high-grade glass wool to reduce heat loss.
  • Equipped with dual air circulation fans for uniform airflow.
  • Features a digital voltmeter for voltage monitoring.
  • Temperature range: Maintains +5°C to 50°C via digital PID controller.
  • Precision: Temperature maintained within ±1°C accuracy.
  • Shaking motion: Speed adjustable from 40 to 240 RPM.
  • Amplitude of motion: 200 mm.
  • Includes a PT-100 sensor for accurate temperature measurement.
  • Operates on 230V ±10%, 50Hz AC power supply.

Model No. Inner Chamber Size (mm) (HXWXD) Temperature Range Flask Capacity
AGN-110 (A) 533X533X830 +5°C TO +50°C 16×500/250 ml
AGN-110 (B) 533X533X533 Ambient to+5°C TO +60°C 16×500/250 ml
Optional:
  1. Internal illumination with 3 Fluorescent Tube with 0-24 timer.
  2. Automatic Voltage Stabilizer 3.5 KVA.
  3. PLC Controller with 21 CFR Software and data recorder.
