Kater’s Reversible Pendulum Steel C.P.

Categories: Educational Equipments

Model No: AGN-2460

It is a compound pendulum constructed on the principle that centre of oscillation and centre of suspension are interchangeable. It consists of a steel rod of 120cm long and 1.0 cm dia capable of two adjustable knife edges facing each other. Two metal weights (made of cast iron) of dimension 7.5×3.75cm (length x diameter) and (3.5 x 3.75cm) respectively can be made to slide along the length of the bar and can be clamped in any position. Two wooden weights exactly similar to metal weights can also slide along the bar. With the help of this apparatus, we can find acceleration due to gravity at a place.

Shere

Technical Specifications

Made of a steel rod, 120 cm long and 1.0 cm in diameter.
Equipped with two adjustable knife edges facing each other.
Includes two cast iron sliding weights (7.5 × 3.75 cm and 3.5 × 3.75 cm) that can be clamped at any position along the rod.
Two wooden weights of similar dimensions also slide along the rod for additional flexibility.
Allows precise determination of acceleration due to gravity at a given location.
