Fume Hood

Fume Hood

Categories: ,

Model No: AGN-160
Fume Hood is a precision-engineered ventilation enclosure designed for safe handling of hazardous or volatile chemical substances. Built for durability and optimal airflow, this fume hood ensures user safety and efficient contaminant extraction, making it ideal for research laboratories, pharmaceutical units, and industrial R&D facilities.
Enquire Now

Shere

Technical Specifications

Construction:
  • Frame Material:
    • Fabricated from 304-grade Stainless Steel, offering excellent corrosion resistance, mechanical strength, and long service life.
  • Interior Lining:
    • Inner surfaces are fully lined with chemical-resistant polypropylene sheets, ensuring superior protection against chemical spills and reactive fumes.
Work Surface:
  • Material:
    • Made from polished black granite, known for its high durability, stain resistance, and ease of cleaning.
  • Sink & Fittings:
    • Integrated polypropylene sink with colour-coded remote-controlled valves for water and gas lines ensures safe and intuitive operation.
Utility & Electricals:
  • Valves:
    • Colour-coded remote valve controls for water and gas enhance safety by allowing operation without direct exposure.
  • Switches & Sockets:
    • Fitted with 2 Nos. 15/5 Amp electrical switch & socket outlets for powering laboratory equipment.
Monitoring & Safety Systems:
  • Digital Airflow Monitor:
    • Real-time monitoring of face velocity and airflow status ensures continuous operator safety and compliance with lab safety standards.
  • Exhaust System:
    • Integrated, high-capacity exhaust blower system efficiently removes contaminated air, minimizing exposure to hazardous fumes.
Fume Hood Product Range
Model No. Description Material Dimensions (W x D x H)
AGN-160-A Fume Hood Stainless Steel (304 Grade) 90 x 160 x 160 cm
AGN-160-B Fume Hood Stainless Steel (304 Grade) 120 x 160 x 160 cm
AGN-160-C Fume Hood Stainless Steel (304 Grade) 120 x 75 x 75 cm
AGN-160-D Fume Hood Stainless Steel (304 Grade) 150 x 75 x 75 cm
AGN-160-E Fume Hood Mild Steel (Epoxy Coated) 90 x 160 x 160 cm
AGN-160-F Fume Hood Mild Steel (Epoxy Coated) 120 x 160 x 160 cm
AGN-160-G Fume Hood Mild Steel (Epoxy Coated) 120 x 75 x 75 cm
AGN-160-H Fume Hood Mild Steel (Epoxy Coated) 150 x 75 x 75 cm
AGN-160-I Fume Hood (with Granite Working Platform) Wooden (Sunmica + Epoxy Interior) 90 x 160 x 160 cm
AGN-160-J Fume Hood (with Granite Working Platform) Wooden (Sunmica + Epoxy Interior) 120 x 160 x 160 cm
AGN-160-K Fume Hood (with Granite Working Platform) Wooden (Sunmica + Epoxy Interior) 120 x 75 x 75 cm
AGN-160-L Demonstration Fume Hood Mild Steel / Custom 90 x 160 x 160 cm
AGN-160-M Fume Hood Stainless Steel (304 Grade) with polypropylene sheet 90 x 160 x 160 cm
AGN-160-N Fume Hood Stainless Steel (304 Grade) with polypropylene sheet 120 x 160 x 160 cm
AGN-160-O Fume Hood Stainless Steel (304 Grade) with polypropylene sheet 120 x 75 x 75 cm
AGN-160-P Fume Hood Stainless Steel (304 Grade) with polypropylene sheet 150 x 75 x 75 cm
AGN-160-Q Fume Hood Mild Steel (Epoxy Coated) with polypropylene sheet 90 x 160 x 160 cm
AGN-160-R Fume Hood Mild Steel (Epoxy Coated) with polypropylene sheet 120 x 160 x 160 cm
AGN-160-S Fume Hood Mild Steel (Epoxy Coated) with polypropylene sheet 120 x 75 x 75 cm
AGN-160-T Fume Hood Mild Steel (Epoxy Coated) with polypropylene sheet 150 x 75 x 75 cm
