DIGITAL MICROSCOPE QHD 2D/3D 360˚

DIGITAL MICROSCOPE QHD 2D/3D 360˚

DIGITAL MICROSCOPE QHD 2D/3D 360˚

‹ DIGITAL MICROSCOPE › DIGITAL PROJECTION MICROSCOPE

Categories: Digital Microscopes, Microscopes

Model No: AGN-QHD-2D/3D 360⁰

Ratio	1:8.3
Model Number	AGN-QHD-2D/3D 360⁰
Brand	AGN
Optical Magnification	0.6-5.0 X
Working distance	86mm
2D/ 3D view	360˚ rotation, 45˚ objective viewing angle

Share

Technical Specifications

Optical Features

Optical Magnification: 0.6–5.0X
Total Magnification: 11–95X (on 12.5″ monitor)
Working Distance: 86mm
Zoom Ratio: 1:8.3
Field of View: 24 × 13.5 mm to 2.88 × 1.62 mm
Lens Mount: Standard C-Mount

2D / 3D Viewing

Manual, switchable 2D / 3D modes
Working Distance and Center Position remain constant
360° rotation with 45° objective viewing angle

Camera & Sensor

Image Sensor: 1–2″ SONY CMOS
Max Resolution: 1920 × 1080 (Full HD)
Pixel Size: 3.75 µm × 3.75 µm
White Balance: Auto / Manual
Brightness Control: Auto / Manual
Record Format: Snapshot / JPG

Monitor Specifications

Display Size: 12.5″ A-SI TFT-LCD / IPS
Resolution: 1920 × 1080
Color Display: 16.7M
Brightness: 300 NIT
Contrast Ratio: 800:1
Viewing Angle: 170° Horizontal & Vertical
Input Interface: HDMI1, HDMI2
USB-A Output: DC 5V / 2A × 3

Illumination

LED Control: 4-zone brightness adjustment
LED Color: White
LED Quantity: 208 pcs
Intensity: 15,000 LUX
Wavelength: 455–457.5 nm
Output Voltage: 12V
Output Power: 8–10W
Working Distance: 35–110 mm

Mechanical & Structural

Material: Aluminum Alloy
Lens Housing Dimensions: Inner Ø 40mm × Height 19mm, Outer Ø 106mm
Base Size: 330 × 300 mm
Height: 328 mm
Scope Holder Diameter: 50 mm
Power Supply:
- Adapter Input: AC 100–240V, 50/60Hz
- Output: DC 12V / 5A / 60W
