DEEP FREEZER -20°C

DEEP FREEZER -20°C

DEEP FREEZER -20°C

[product_navigation]

Categories:

Model No: AGN-154A
Deep Freezer is a low-temperature storage unit designed for the safe and long-term preservation of temperature-sensitive samples, vaccines, enzymes, and biological materials. It is widely used in laboratories, hospitals, research institutions, and pharmaceutical facilities.
Enquire Now

Share

Technical Specifications

  • Construction:
    • Double-walled design for enhanced thermal insulation and durability.
    • Outer body: Made from mild steel (MS) with epoxy powder coating or optionally stainless steel for corrosion resistance and durability.
    • Inner chamber and trays: Fabricated from stainless steel (SS) sheet for hygienic and long-lasting performance.
    • Insulation: High-grade PUF insulation between walls to minimize thermal loss and improve energy efficiency.
  • Design Variants:
    • Available in both Vertical and Horizontal models to suit space and storage requirements.
    • Inner transparent acrylic door allows internal visibility without disturbing the temperature conditions.
  • Monitoring & Control:
    • Equipped with a mechanical voltage indicator for monitoring input voltage levels.
    • Microprocessor-based PID temperature controller with integrated digital temperature display.
    • Provides a temperature range from ambient to -20°C with high accuracy of ±0.5°C.
  • Cooling System:
    • Efficient refrigeration system ensures reliable performance even at low temperatures.
    • Designed for consistent cooling and energy-efficient operation.
  • Power Supply:
    • Operates on 220/230 Volt AC, 50 Hz standard electrical supply.

Model No. Inner Size (W x D x H) Capacity Cubic Feet / Liters
AGN-153 A 375 x 500 x 605mm 4 / 112
AGN-153 B 505 x 410 x 830mm 6 / 171
AGN-153 C 570 x 550 x 875mm 10 / 280
AGN-153 D 650 x 580 x 900mm 12 / 340
  Optional:
  1. Chart Recorder for Blood Bank Refrigerated.
  2. HMI (Touch Screen) Controller with Data recorder and Software.
  3. Automatic Voltage stabilizer.
