Condensers, Dimroth, with Screw Thread Connectors

Condensers, Dimroth, with Screw Thread Connectors

Model No: AGN.2512
  • Complies with DIN 12591 standards.
  • Manufactured from ASTM E-438, Type-1, Class A, Boro 3.3 glass.
  • Equipped with plastic screw thread connectors.

Shere

Technical Specifications

Cat. No. Socket Size Cone Size Effective Length (mm) Connector Pack of
AGN.2512.01 14/23 14/23 160 Screw Thread 1
AGN.2512.02 19/26 19/26 160 Screw Thread 1
AGN.2512.03 19/26 19/26 250 Screw Thread 1
AGN.2512.04 24/29 24/29 250 Screw Thread 1
AGN.2512.05 29/32 29/32 250 Screw Thread 1
AGN.2512.06 24/29 24/29 300 Screw Thread 1
AGN.2512.07 29/32 29/32 300 Screw Thread 1
AGN.2512.08 29/32 29/32 400 Screw Thread 1
