B.O.D. INCUBATOR AGN-109

BOD incubator is a specialized laboratory device designed for controlled temperature incubation, primarily used in microbiology, biotechnology, and environmental labs. It provides a stable environment for growing cultures, performing BOD tests, and conducting other applications requiring precise low-temperature conditions. The unit typically features double-wall construction, stainless steel inner chamber, efficient insulation, temperature control (usually from 5°C to 50°C), and uniform airflow to maintain consistent conditions throughout the chamber.

Shere

Technical Specifications

  • Built with a standard double-wall construction
  • Inner chamber made from highly polished grade 304 stainless steel
  • Outer casing constructed of mild steel, coated with epoxy powder paint
  • Wall gap filled with high-quality glass wool for insulation and reduced heat loss
  • Equipped with two air circulation fans and a digital voltmeter
  • Temperature range from +5°C to 50°C controlled by a digital PID temperature controller
  • Temperature accuracy of ±1°C
  • Mounted on castor wheels for easy mobility
  • Uses a highly accurate PT-100 temperature sensor
  • Operates on 230±10V, 50Hz power supply

Model No. Inner Chamber Size (mm) (HXWXD) Capacity (Cu.ft) Capacity (Liters)
AGN-109 (A) 455X410X610 4.1 112
AGN-109 (B) 505X415X830 6.1 171
AGN-109 (C) 565X565X865 10.1 280
AGN-109 (D) 650X580X900 12.1 336
AGN-109 (E) 700X650X900 15.1 420
  Optional:
  1. Co2 air mixer nozzle.
  2. Internal illumination with 3 fluorescent tubes with 0-24 timer.
  3. Automatic Voltage Stabilizer 3-5 KVA
  4. PLC Controller with 21 CFR Software and data recorder
