Automatic Water Distillation Equipment Cabinet Model

‹ Arsenic Apparatus › Carbaryl Content Determination Apparatus

Categories: Distillations, Laboratory Glassware

Model No: AGN.3553

Designed for precise control in research laboratories, hospitals, and similar applications, this distillation unit features advanced microprocessor-based electronic circuitry and an alphanumeric LCD to display operational messages. An integrated alarm system notifies the user whenever attention is required.

The quality of the output depends on the quality of the inlet feed water. For high-purity, low-conductivity water, Quartz Water Distillation is recommended. All parameters are measured under standard test conditions.

Technical Specifications

Key Features:

Replaceable Silica-Sheathed (Quartz) Heater: Horizontal quartz jacket fitted with a removable silica heater and screw-threaded connectors for easy cleaning and scale removal.
Energy Efficiency: Recirculates cooling water from the condenser back into the boiling chamber to save energy.
Boiler Design: Equipped with a replaceable side-overflow for easy draining and cleaning, minimizing breakage risks.
Easy Access: Front cover is easily removable, providing simple access to glass parts.
Electrical Power: 220/240 V, 50/60 Hz, single-phase supply.

Additional Safety & Convenience Features:

Gate Valve: Reduces cooling water wastage during power failures.
Flow Switch: Automatically shuts off the unit in case of cooling water failure.
Temperature Switch: Protects glass parts by turning off the heater if the water level falls too low.
Reservoir Level Sensor: Automatically switches the unit on/off based on the water level to save energy.
Optional Reservoirs: Available in 5 L, 10 L, or 20 L capacity, made of Borosilicate Glass or polypropylene at extra cost.

Output Capacity	pH	Conductivity ( µS/cm)	Cooling Water Requirement (Ltr./min.)	Power Rating (kW)
2.0	5.5 to 6.0	<3.0	1.5	1.5
4.0	5.5 to 6.0	<3.0	2.5	3.0

Cat. No.	Output (Ltr./Hr.)	Stage
AGN.3553.01	2	Single Stage
AGN.3553.02	4	Single Stage
AGN.3553.03	2	Double Stage
AGN.3553.04	4	Double Stage
